Features

• Smart Self-Regulating Thermal Control
  The PTC core adjusts resistance as temperature changes, preventing overheating—no thermostat needed.
• Silent, Energy-Efficient Convection Heating
  Aluminum fins maximize heat dispersion into ambient air without a fan, preserving energy and eliminating noise.
• Versatile Mounting & Multi-Stage Options
  Various sizes and mounting objects available, plus optional 2- or 3-stage heating control built into one unit.
• Broad Applications Spectrum
  From PC motherboard protection to steam irons, medical devices, air purifiers, and frost prevention.
• EMF-free, passes EMI, EMC tests

Our Multi-Stage Heating PTC Heat Conductor provides higher flexibility in temperature control, by allowing two or three temperature settings in a single heating unit. Multistage heating unit can be designed into all LCH types (LCH-A to New Model LCH-M) PTC heat conductors.

Why KLC PTC Heat Conductors Are Better

1. Self-Regulating Safety
Automatically limits current as temperature rises, preventing overheating and eliminating the need for external thermal controls.

2. Silent & Maintenance-Free
Aluminum fins enable natural convection heating without fans or moving parts, ensuring quiet and reliable operation.

3. Wide Voltage & Power Range
Compatible with AC/DC 12 V to 600 V and Max power outputs from up to 2000 W, suitable for everything from sensitive electronics to industrial systems.

4. Multi-Stage Heating Option
Optional 2- or 3-stage heating modules provide flexible temperature control within one compact unit.

5. Proven Reliability Across Industries
Deployed worldwide in electronics, household appliances, medical devices, and industrial equipment.

6. Energy-Saving & Eco-Friendly
Lower energy consumption, RoHS / REACH compliance, and long service life reduce both operating cost and environmental impact.

Safety Regulations Compliance (UL / CSA / CE)

• UL (Underwriters Laboratories, USA)
  Ensures electrical safety for North American markets, covering fire resistance, electric shock protection, and material compliance.
• CSA (Canadian Standards Association, Canada)
  Guarantees safe, reliable long-term performance in Canadian regulatory environments, similar to UL but tailored to Canada.
• CE (Conformité Européenne, Europe)
  Required for EU markets, ensuring compliance with European directives on safety, health, and environmental protection, including LVD and EMC requirements.

KLC Commitment: PTC Heat Conductors can be manufactured and tested to meet UL, CSA, and CE standards, offering customers globally compliant heating solutions.

Typical Applications

• PC Motherboard Heating & Moisture Control
• Steam Irons & Beauty Devices
• Frost Protection & Health & Medical Appliances

Technical Specifications at a Glance

• Max Power : up ~ 2000W
• Surface Temperature : 60°C ~ 240°C
• Voltage :AC/DC 12V~520V
• Standard Lead Wire :22AWG 210mm (black)

FAQ – KLC PTC Heat Conductors

Q1: What is a PTC Heat Conductor?
A PTC (Positive Temperature Coefficient) Heat Conductor is a self-regulating heating element that uses PTC ceramic material. As the temperature rises, resistance increases, automatically limiting the current. This feature ensures safety, prevents overheating, and makes external temperature control unnecessary.

Q2: What are the advantages of KLC’s PTC Heat Conductors?

• Self-regulating thermal behavior (no thermostat needed)

• Safe and reliable — no risk of overheating

• Silent natural convection heating (no fan required)

• Wide voltage compatibility (AC/DC 12 V – 600 V)

• Energy-saving, fail-safe design

• Available in single or multi-stage heating versions

Q3: What are the typical applications?
KLC PTC Heat Conductors are widely used in:

• Moisture and frost prevention in electronics (e.g., PC motherboards)

• Household appliances such as steam irons and air purifiers

• Beauty and medical devices (skin care tools, sterilizers)

• Industrial control equipment requiring silent, reliable heating

Q4: How does the self-regulating function work?
When the conductor heats up, the resistance of the PTC ceramic element increases. This reduces current flow and stabilizes the temperature at a safe level. If ambient temperature drops or airflow increases, the conductor automatically delivers more heat output.

Q5: What are the available specifications?

• Max Power: UP to 2000 W

• Surface temperature: 60 °C – 240 °C

• Voltage range: AC/DC12V – 600 V

• Standard lead wire: 22 AWG, 210 mm

• Special option: 2- or 3-stage heating in one unit

Q6: Can PTC Heat Conductors be used continuously?
Yes. Thanks to their self-limiting property, KLC PTC Heat Conductors can operate continuously without overheating, as long as they are used within the specified voltage and ambient conditions.

Q7: Do PTC Heat Conductors require fans for operation?
No. KLC’s design uses aluminum fins for natural convection, which allows efficient heat transfer to the surrounding air without the need for a fan. However, additional airflow can enhance heat output if needed.

Q8: What safety standards do they comply with?
KLC PTC Heat Conductors are designed to meet international safety and environmental standards, including RoHS compliance. Custom designs can also be produced to meet UL, VDE, or CSA certification requirements.

Q9: Can KLC provide custom designs?
Yes. KLC offers tailored solutions, including custom dimensions, mounting methods, power ratings, and multi-stage heating configurations to fit different application needs.

Q10: How does airflow affect the heating performance?
With higher airflow, the surface temperature decreases, but the power consumption increases—resulting in more heat output. With lower airflow, the temperature increases, but power consumption decreases. This natural balance ensures stable, energy-efficient operation.
